Yaw Wind Generator Controller for 20KW On Grid Wind Power System

FOB Reference Price:Get Latest Price
$3,000.00 - $5,000.00 / Piece | 2 Piece/Pieces (Min. Order)
Type:
Wind Power Generator On Grid Wind Charge Controller
Rated Power:
20KW
Shipping:
Support Sea freight
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 5 Pieces)
Customized packaging (Min. Order: 50 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
Deming
Model Number:
FKJ-B-Y20KW
Wind Turbine Controller:
Yaw Wind Generator Controller for 20KW On Grid Wind Power System
Wind turbine rated power:
20KW
Wind turbine rated voltage:
AC380-400V
Function:
Rectifier,control,DC output,Yaw
PWM constant voltage:
≥520dc
Wind turbine 3-phase dump load voltage 1:
540±5Vdc
Wind turbine 3-phase dump load voltage 2:
550±5Vdc
Wind 3-phase dump load time-lapse:
12-20 min
PWM dump load fuse:
80A
Fuse of DC output:
100A
Supply Ability
Supply Ability:
100 Piece/Pieces per Month Yaw Wind Generator Controller for 20KW On Grid Wind Power Syst
Packaging & Delivery
Packaging Details
1PCS/Carton
Yaw Wind Generator Controller for 20KW On Grid Wind Power System
Port
Qingdao,Shenzhen,Tianjian,Shanghai
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 7 To be negotiated

 Yaw Wind Generator Controller for 20KW On Grid Wind Power System

Functions



()-



Yaw On Grid Wind Turbine Controller Product Characteristics



1. Siemens PLC

2. Siemens touch screen

3. Built-in encoder

4.Built-in anemometer

5.Built-in wind vane

6. Built-in frequency converter (optional according to wind turbine)

7. Display voltage, current, power and other parameters

8. Yaw, cable release, wind speed, wind direction, yaw angle degrees can be set up

9. Support mobile,computer web monitoring (optional wireless monitor module)

10. Adopt the patented design scheme, which saves complicated wiring, installation, debugging convenient

Product Photo

Product photo







123

Technical Parameter

Technical Parameters



Type

FKJ-B-Y20KW

Wind turbine rated power

20KW

Wind turbine Max. power

 40KW

Wind turbine rated voltage

 AC380V-400V

Function

Rectifier,control,DC output,Yaw

Automatic protection function

Over voltage protection, network electric cut off protection, regulated supply output, arrester

Manual function

Manual brake, reset, emergency switch

Display mode

LCD

Display content

Wind turbine voltage, current, power; DC output voltage, DC output current, DC output power, total power.

PWM constant voltage (Settable)

 ≥520dc

wind turbine 3-phase dump load voltage1(Settable)



540±5Vdc

wind turbine 3-phase dump load voltage2(Settable)



550±5Vdc

Time-lapse of the wind turbine 3-phase dump load2



12-20 min

PWM dump load fuse

 80A

Fuse of DC output

 100A

Work environment temperature

-30-60°C

Relative humidity

<90% No condensation

Noise (1m)

<40dB

Degree of protection

IP20(Indoor)

Cooling method

Forced air cooling

Extral control function is (optional)

yawing, variable pitch, mechanical brake, hydraulic brake, electromagnetism brake

Communication interface (optional)

RS485/USB/GPRS/WIFI/Ethernet

Temperature compensation(optional)

-4mv/°C/2V,-35°C~+80°C, Accuracy:±1°C

Size of the controller (mm)

680*630*1360

Weight of the controller

130Kg

Size of the dump load (mm)

850*740*580mm

Weight of the dump load

 110Kg



*Above parameter only for referenceCould be custom made to user specifications.

Project case

50KW Wind Turbine Charge Controller for On Grid System

After-Sales Service

Optional Parts

  Service guarantee

         As our corporate users, you enjoy the following service:
        (1) The machine warranty for free in 2 year;
        (2) Technical support;
        (3) Within 24 hours for respond after receiving notification;
        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.
        However, any of the following situation happened, are not included in the warranty:


       (1) Non-permitted by the company, went ahead with repair and damage;
       (2) Install or modify arbitrarily;
       (3) Incorrect operation or use;
       (4) Do not depending on the manual to do cleaning or maintenance;
       (5) Abnormal environment condition exceed the specifications, result in damage;
       (6) The deliberate destruction of man-made;
       (7) Irresistible natural disasters.
