Off grid Three phase inverter 60KVA

FOB Reference Price:Get Latest Price
$7,734.00 - $9,062.00 / Pieces | 1 Piece/Pieces (Min. Order)
Output Power:
60KVA 60kw
Lead Time:
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 Negotiable
Customization:
Customized logo (Min. Order: 5 Pieces)
Customized packaging (Min. Order: 10 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Deming
Model Number:
NB220-60KSZ
Output Type:
three phase
Size:
660*1300*1600mm
Weight:
500KG
Input Voltage:
120V/220V/240V/380V/480V
Output Voltage:
220V/380V/400V
Type:
DC/AC Inverters
Output Frequency:
50HZ/60HZ
Output Current:
158A
Color:
Gray
Warranty:
1 Year
Output waveform:
Pure Sine Wave Output
Supply Ability
Supply Ability:
10000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Wood packaging
Port
qingdao
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 To be negotiated

60KVA off grid three phase inverter technical parameters



Type

NB480-60KSZ

NB220-60KSZ

NB380-60KSZ

DC input

Input rated voltage

480 VDC

220 VDC

380 VDC

Input rated current

125A

272.7A

157.9 A

Input DC voltage range

400-600 VDC

180-300 VDC

300-490VDC



AC input

Allow input voltage range

220 VAC /380 VAC / 400 VAC  ± 15% VAC

Input rated current

157.5A / 91A / 86.6 A

Bypass transfer time

4 ms

AC output

Rated capacity

60KVA

Output rated power

48KW

Output rated voltage and frequency

220 VAC / 380 VAC / 400 VAC ,50Hz / 60Hz

Output rated current

157.5A / 91A / 86.6 A

Output voltage accuracy

220 VAC /380 VAC / 400 VAC  ± 2%

Output frequency accuracy

50Hz / 60Hz ±0.05%

Waveform distortion (THD). (Linear load)

≤3%

Dynamic response time (Load 0←→100%)

5%

Power factor (PF)

0.8

Overload capacity

120%, 3minutes,150%,10second

Crest factor (CF)

3:1

Inverter efficiency

90%

Working Environment

Dielectric strength

1500VAC,1minute

Noise (1m)

≤50dB

Ambient temperature

-10~+50℃

Humidity

0~90%,No condensation

Altitude

≤3000 m

High than 3000m rated power should be reduced

Production function

Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection

Size

 660*1300*1600mm

Weight

 500KG



Schematic diagram:



Parts

  Service guarantee

         As our corporate users, you enjoy the following service:

        (1) The machine warranty for free in 2 year;

        (2) Technical support;

        (3) Within 24 hours for respond after receiving notification;

        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.



        However, any of the following situation happened, are not included in the warranty:

       (1) Non-permitted by the company, went ahead with repair and damage;

       (2) Install or modify arbitrarily;

       (3) Incorrect operation or use;

       (4) Do not depending on the manual to do cleaning or maintenance;

       (5) Abnormal environment condition exceed the specifications, result in damage;

       (6) The deliberate destruction of man-made;

       (7) Irresistible natural disasters.
