Pure sine wave power inverter 1000W

FOB Reference Price:Get Latest Price
$150.00 - $250.00 / Pieces | 1 Piece/Pieces (Min. Order)
Output Power:
1 - 200KW
Lead Time:
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 Negotiable
Customization:
Customized logo (Min. Order: 5 Pieces)
Customized packaging (Min. Order: 10 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
DEMING
Model Number:
DM-SHI1000
Output Type:
Single
Size:
295*208*98
Weight:
3.3kg
Input Voltage:
24V/48V
Output Voltage:
110V/220V/230V/240V
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
9A
Battery group rated voltage:
12/24/48Vdc
Display mode:
LCD
Communication interface (optional):
RS485/USB/GPRS/Ethernet
Warranty:
1 Year
Output waveform:
Pure Sine Wave Output
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton package
Port
Qingdao,Shanghai, Shenzhen
Lead Time :
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 To be negotiated

Product Description





1000W off grid pure sine wave inverter technical parameters



Type

DM-SHI1000-42

DM-SHI1000-22

Inverter

Rated power

1000W

1000W

DC input rated voltage

DC48V

DC24V

DC voltage rang

43.2-64Vdc

21.6-32Vdc

Low voltage protection

43.2Vdc±1%

21.6Vdc±1%

No load current

≤0.35A

≤0.45A

Continuous power

1000W

1000W

 Power 10 sec1500W

1500W

Power 1.5 sec2000W

2000W

Surge power2250W2250W

Output AC voltage

110 – 120 – 220 VAC±3%/230Vac10%

Output Current

9A – 8.3A – 4.5A – 4.3A

Rated frequency

50Hz / 60Hz ±0.2%

Wave

Pure sine wave

THD

≤3% (Linear load)

Power factor (PF)

0.8

Crest factor (CF)

3:1

Max. efficiency

92%

Working Environment

Noise (1m)

≤50dB

Ambient temperature

-25~+50℃

Humidity

0~95%, No condensation

Altitude

Higher than 3000m rated power should be reduced

Other

Dielectric strength

1500VAC,1minute

Degree of protection

IP20(Indoor)

*Communication interface

RS485/USB/GPRS/Ethernet

Size

295*208*98MM

Weight

                                 3.3kg

Function

 Input reverse protection, over current  protection, short circuit  protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection etc.

*It means the function is optional, if you want it, please tell us before your order.

*Above parameter only for reference. Could be custom made to user specificat



Parts

  Service guarantee

         As our corporate users, you enjoy the following service:

        (1) The machine warranty for free in 2 year;

        (2) Technical support;

        (3) Within 24 hours for respond after receiving notification;

        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.



        However, any of the following situation happened, are not included in the warranty:

       (1) Non-permitted by the company, went ahead with repair and damage;

       (2) Install or modify arbitrarily;

       (3) Incorrect operation or use;

       (4) Do not depending on the manual to do cleaning or maintenance;

       (5) Abnormal environment condition exceed the specifications, result in damage;

       (6) The deliberate destruction of man-made;

       (7) Irresistible natural disasters.
