Pure sine wave power inverter 600W

FOB Reference Price:Get Latest Price
$100.00 - $200.00 / Pieces | 1 Piece/Pieces (Min. Order)
Output Power:
1 - 200KW
Shipping:
Support Sea freight
Lead Time:
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 Negotiable
Customization:
Customized logo (Min. Order: 5 Pieces)
Customized packaging (Min. Order: 10 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
DEMING
Model Number:
DM-SHI600-12
Output Type:
Single
Size:
280*166*74.3
Weight:
1.8kg
Input Voltage:
12V/24V/48V
Output Voltage:
110V/220V/230V/240V
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
5.5A
Battery group rated voltage:
12/24/48Vdc
Display mode:
LCD
Communication interface (optional):
RS485/USB/GPRS/Ethernet
Warranty:
1 Year
Output waveform:
Pure Sine Wave Output
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton package
Port
Qingdao,Shanghai, Shenzhen
Lead Time :
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 14 To be negotiated



600W off grid pure sine wave inverter technical parameters



Type

DM-SHI600-12

DM-SHI600-22

Inverter

Rated power

600W

600W

DC input rated voltage

DC12V

DC24V

DC voltage rang

10.8-16Vdc

21.6-32Vdc

Low voltage protection

10.8Vdc±1%

21.6Vdc±1%

No load current

≤0.8A

≤0.45A

Continuous power

600W

600W

 Power 10 sec900W

900W

Power 1.5 sec1200W

1200W

Surge power1350W1350W

Output AC voltage

110 – 120 – 220 VAC±3%/230Vac10%

Output Current

5.5A – 5A – 2.7A – 2.6A

Rated frequency

50Hz / 60Hz ±0.2%

Wave

Pure sine wave

THD

≤3% (Linear load)

Power factor (PF)

0.8

Crest factor (CF)

3:1

Max. efficiency

92%

Working Environment

Noise (1m)

≤50dB

Ambient temperature

-25~+50℃

Humidity

0~95%, No condensation

Altitude

Higher than 3000m rated power should be reduced

Other

Dielectric strength

1500VAC,1minute

Degree of protection

IP20(Indoor)

*Communication interface

RS485/USB/GPRS/Ethernet

Size

295*186*82MM

Weight

                                 2.3kg

Function

 Input reverse protection, over current  protection, short circuit  protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection etc.

*It means the function is optional, if you want it, please tell us before your order.

*Above parameter only for reference. Could be custom made to user specificat



Parts

  Service guarantee

         As our corporate users, you enjoy the following service:

        (1) The machine warranty for free in 2 year;

        (2) Technical support;

        (3) Within 24 hours for respond after receiving notification;

        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.



        However, any of the following situation happened, are not included in the warranty:

       (1) Non-permitted by the company, went ahead with repair and damage;

       (2) Install or modify arbitrarily;

       (3) Incorrect operation or use;

       (4) Do not depending on the manual to do cleaning or maintenance;

       (5) Abnormal environment condition exceed the specifications, result in damage;

       (6) The deliberate destruction of man-made;

       (7) Irresistible natural disasters.
