Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine

FOB Reference Price:Get Latest Price
$200.00 - $300.00 / Pieces | 1 Piece/Pieces (Min. Order)
Rated Voltage:
24V
Maximum Current:
42A
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 2 Negotiable
Customization:
Customized logo (Min. Order: 50 Pieces)
Customized packaging (Min. Order: 100 Pieces)

More

Graphic customization (Min. Order: 50 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Brand Name:
Deming
Model Number:
FKJ-B 1KW24V
Type:
PWM
Application:
Charger Controller, Wind Controller
Work Time (h):
24
Max PV Power:
1000w
Max PV Voltage:
24V
Product name:
Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine
Wind turbine rated power:
1KW
Battery:
24Vdc
Function:
Rectifier,charge, control, *DC output
Display mode:
LCD
PWM constant pressure voltage:
>29Vdc
Wind turbine 3-phase dump load voltage:
30±1Vdc
Wind turbine recharge voltage:
27±1Vdc
Communication Port:
RS485/WiFi/GPRS/Ethnet /App
Warranty:
2 Years
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month 1KW Horizontal Axis Wind Generator Charge Controller for Home
Packaging & Delivery
Packaging Details
paper carton /wooden case
Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine
Controller :480*360*240mm 17 Kgs Packing Size:590*420*330mm 19 Kgs
Dump load:410*290*120mm 8 Kgs Packing Size:490*370*190mm 10Kgs
Port
Qingdao,Shanghai,Tianjin,Shenzhen
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 2 To be negotiated

 Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine

Function

Off-Grid PWM Wind Turbine (Wind generator) Controller

FKJ-B model off grid PWM wind turbine controller Product Characteristics

1. The product is manufactured according the JB/T6939.1-2004 industrial standard and GB/T19115.1-2003 national standard also with users’ technical requirements.

2. Big LCD display.The images display working state visually.Various data show: real-time wind turbine voltage,current,power;solar panel voltage,current,power;battery group voltage, charge current.

3. Two sets of control systems:PWM constant voltage system and three-phase dump load system.

4. When strong or super-strong wind conditions, PWM control to ensure battery charged by wind turbine with constant voltage and current.

5. When the battery disconnect or damage,three-phase dump load will start automatically to avoid the wind turbine idling and runaway accident.

6. The protection function of battery: polarity reverse protection, disconnection and damage protection.

7. Over-charging protection of the battery: When the battery is full, the three-phase dump load will work, wind turbine will brake and stop charge battery.

8. Auto recharging of battery: When battery voltage reduces to 108% of the rated voltage,it stops three-phase dump load to recharge battery automatically.

9. The controller is equipped with manual brake switch. To use this switch, wind turbine will carry out three-phase dump load forcibly.

10. The inside of the controller is equipped with surge arrester. Contain the over voltage into the wind turbine under the bearable voltage of the equipment or system. On the other way, to conduct the strong lightening current into the earth directly to avoid any damage of equipment.

* Solar panel control system is optional.Based on customers' requirement.

* Disel generator port is optional.Control the generator start and stop automatically

* Adopt Modbus Communication protocol. Convenient to carry out the secondary development.

* Adjusting the technical specification via RS485 is available.Convenient to adjust the different wind turbines for professional customers.

* Support WIFI and GPRS.Customers can monitor the real-time working state of the on grid wind power system via PC and mobile and query history working sate.Both Android and OS are compatible in Mobile.

* For the different wind turbine, the controller can be equipped with mechanical yawing, Rotate tail control, furled empennage, mechanical brake,hydraulic brake, electromagnetism brake and other brake functions. Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine

Product Photo











 Schematic diagram

  Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine

Technical Parameter







Type

1KW12V

1KW-24Vdc

1KW-48Vdc

Wind turbine rated power

1KW

1KW

1KW

Wind turbine max. power

2KW

2KW

2KW

*Solar panel power

300Wp

300Wp

300Wp

Battery

12Vdc

24Vdc

48Vdc

Function

Rectifier,charge, control, *DC output

Automatic protection function

Over voltage protection, constant voltage charge, arrester

Manual function

Manual brake

Display mode

LCD+LED

Display content

Wind turbine voltage, current, power; solar panel voltage, current, power; battery voltage, charge current

PWM constant pressure voltage

>14Vdc

>29Vdc

>58Vdc

Wind turbine 3-phase dump load voltage

15±1Vdc

30±1Vdc

60±1Vdc

Wind turbine recharge voltage

13.5±1Vdc

27±1Vdc

54±1Vdc

* Solar control stop charging voltage

15±1Vdc

29±1Vdc

58±1Vdc

*Solar control recharge voltage

<14Vdc

<29Vdc

<58Vdc

*Diesel generator starting voltage

10±1Vdc

20±1Vdc

40±1Vdc

*Diesel generator off voltage

13.5±1Vdc

27±1Vdc

54±1Vdc

Self-provided battery connecting wire

>16 mm²

>8mm²

>6mm²

PWM fuse

100A

50A

25A

* Solar fuse

32A

16A

10A

Charging fuse

125A

63A

40A

Work environment temperature

-30-60°C

Relative humidity

<90% No condensation

Noise (1m)

<40dB

Degree of protection

IP20(Indoor)IP65 (Outdoors)

Cooling method

Forced air cooling

* Extral Control function (optional)

Yawing, variable pitch, mechanical brake, hydraulic brake, electromagnetism brake

* Communication interface (optional)

RS485/USB/GPRS/WIFI/Ethernet

*Temperature compensation (optional)

-4mv/°C/2V,-35°C~+80°C,Accuracy:±1°C

Controller Size (mm)  Weight (kg)

510*360*240

  17 Kg

510*360*240

  17 Kg

510*360*240

17 Kg

Dump load Size (mm)  Weight (kg)

290*250*120             5 Kg

290*250*120          5 Kg

290*250*120              5 Kg

*Above parameter only for reference. Could be custom made to user specifications.

 Wind Generator Charge Controller 1KW24V for 1000W Wind Turbine

Packaging & Shipping



After-Sales Service

  Service guarantee

         As our corporate users, you enjoy the following service:
        (1) The machine warranty for free in 2 year;
        (2) Technical support;
        (3) Within 24 hours for respond after receiving notification;
        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.
        However, any of the following situation happened, are not included in the warranty:
       (1) Non-permitted by the company, went ahead with repair and damage;
       (2) Install or modify arbitrarily;
       (3) Incorrect operation or use;
       (4) Do not depending on the manual to do cleaning or maintenance;
       (5) Abnormal environment condition exceed the specifications, result in damage;
       (6) The deliberate destruction of man-made;
       (7) Irresistible natural disasters.
