solar charge controller 192V

FOB Reference Price:Get Latest Price
US $340-670 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
deming
Model Number:
192V
Application:
Solar System Controller
Rated Voltage:
192V
Maximum Current:
80A
Battery group rated voltage:
192Vdc
PV open circuit voltage:
500V
MPPT rang vol.:
160V-240V
PV Rated current:
30A/50A/60A/80A
Input PV module road number:
1
Display mode:
LCD
Floating Charge Voltage (adjustable):
220Vdc
Communication interface (optional):
RS485/USB/GPRS/Ethernet
Product size (mm):
520*430*200
Weight:
12KG
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Carton package
Port
Qingdao,Shanghai, Shenzhen
Lead Time :
3-15 days
Solar Charge Controller 192V 30A/50A/60A/80A with factory price

Product Overviews

functional

Properties of the solar charge controller

1. Design for off-grid solar power system.

2. Applicable to different kinds of batteries.

3. Modular design with simple structure and easy maintenance.

4. Automatic power control function.

5. LCD display: Solar panel current, solar panel voltage, solar panel power, battery group voltage, charge current.

6. MODBUS protocol. The problem that the protocol cant be compatible with other devices is solved. It is convenient to do secondary development.

7. Add the protection function of charge module. When batteries are broken or open circuit, inverter power the loads directly via controller, the charge module wont be damaged.

8. Battery protection is added. When there is fault on charge module, disconnect the battery, to prevent the over-charge of battery(high voltage is optional)

9.Perfect protection function: Solar reverse charge protection, Solar reverse connection   protection, Battery reverse connection protection, Battery overcharge protection, Battery over current protection etc ,thus the system has higher reliability.



Detailed Images


         5

         solar inside







technical

Technical parameters for 192V MPPT solar charge controller

Model

192V30A

192V50A

192V60A

192V80A

Battery group rated voltage

192Vdc

192Vdc

192Vdc

192Vdc

PV open circuit voltage

500V

500V

500V

500V

PV Rated current

30A

50A

60A

80A

PV Max. power

5760Wp

9600Wp

11520Wp

15360Wp

Input PV module road number

1

1

1

1

Function

Auto stop charge, auto recharge voltage; Protection: connecting contrary, over current, short circuit, over heat etc.

Display mode

LCD

Display content

solar panel voltage, solar panel current, solar panel power, battery voltage, charge current

Floating Charge Voltage (adjustable)

220Vdc

220Vdc

220Vdc

220Vdc

Stop charge voltage

232Vdc

232Vdc

232Vdc

232Vdc

Recharge voltage

216Vdc

216Vdc

216Vdc

216Vdc

Voltage drop between PV and battery

1.5V

Max itself power consumption

100mA-150mA

Work environment temperature

-30-60°C

Relative humidity

<90% No condensation

Applicable altitude

<3000m

The rated power should be reduced when it is higher

than 2000m

Noise (1m)

<40dB

Degree of protection

IP20(Indoor)

Cooling method

Forced air cooling

*Communication interface (optional)

RS485/USB/GPRS/Ethernet

*Temperature compensation(optional)

-4mv/°C/2V,-35°C~+80°C,Accuracy:±1°C

Product size (mm)

520*430*200

Weight

12Kg

*Above parameter only for reference. Could be custom made to user specifications.





Parts

Parts2017s

     Service guarantee

         As our corporate users, you enjoy the following service:

        (1) The machine warranty for free in 2 year;

        (2) Technical support;

        (3) Within 24 hours for respond after receiving notification;

        (4) Cost maintenance forever.

        When you confirm the failure of equipment, please promptly contact us and provide the equipment model and complete description of the problem.



        However, any of the following situation happened, are not included in the warranty:

       (1) Non-permitted by the company, went ahead with repair and damage;

       (2) Install or modify arbitrarily;

       (3) Incorrect operation or use;

       (4) Do not depending on the manual to do cleaning or maintenance;

       (5) Abnormal environment condition exceed the specifications, result in damage;

       (6) The deliberate destruction of man-made;

       (7) Irresistible natural disasters.
